Klauke MCK120120 Multi-Range Copper C-Clamp 120mm² - Tin Plated

Klauke MCK120120 Multi-Range Copper C-Clamp 120mm² - Tin Plated

Manufacturer: KLAUKE

SKU: MCK120120

EAN13: 4012078479707

Back order for delivery on 23rd November 2026

Multi-range C-clamp with a cross section of 120mm² for round multi-stranded cable

Made from copper (ETP), which is tin plated

No need to cut the main conductor

Suitable for branching off different conductor cross-sections

Click here for product info
£13.03 £10.86
In stock
GBP

Free UK Delivery on orders over £75 including VAT

Quantity Price Each Ex VAT Price Each Inc VAT
1+ £10.86 £13.03
10+ £9.78 £11.74
50+ £8.31 £9.98
100+ £7.33 £8.79
1000+ £6.36 £7.63
Live Chat Icon

Need shopping help?

Ask a Specialist

Product Information

  • Multi-range C-clamp with a cross section of 120mm² for round multi-stranded cable.
  • For use on non-tension copper cables such as those according to DIN 48201-1 but is also ideal for clamping identical conductor cross-sections to DIN EN 60228 Cl. 1 and 2.
  • There is no need to cut the main conductor with this clamp.
  • Made from copper (ETP), which is tin plated to protect against corrosion.

Cable Compatibility

Cable typeDescription
Single-strand conductor (Class 1 according to DIN EN 60228) made from bright finish or metal-encased annealed copper, aluminium or aluminium alloy respectively.
Multi-strand uncompacted conductor (Class 2 according to DIN EN 60228) made from bright finish or metal-encased annealed copper, aluminium or aluminium alloy respectively.
Multi-strand compacted conductor (Class 2 according to DIN EN 60228) made from bright finish or metal-encased annealed copper, aluminium or aluminium alloy respectively.
Copper stranded conductors (DIN 48201-1), aluminium or aluminium alloy conductors for overhead lines (DIN EN 50182).

Technical Details

Manufacturer Klauke
Clamp Type Multi-Range
Maximum Tap Conductor [Cross-section pass round multi-stranded/round single solid] 35mm² - 120mm²
Minimum Pass [Cross-section round multi-stranded/round single solid] 120mm²
Minimum Tap Conductor [Cross-section pass round multi-stranded/round single solid] 35mm² -120mm²
Total Length 30 mm
Weight 0.1655 kg
Weight Per 100 Pieces 16.55 kg
Width 45 mm
Packaged Weight 0.1655 kg
PLP1 Multi-range C-clamp for 120mm² round multi-stranded cable
PLP2 Made from copper (ETP), which is tin plated
PLP3 No need to cut the main conductor
PLP4 Suitable for branching off different conductor cross-sections
