Ingersoll Rand W9491-K4E-EU 1" Square Drive 20V Cordless Impact Wrench Set - 3525Nm

Ingersoll Rand W9491-K4E-EU 1" Square Drive 20V Cordless Impact Wrench Set - 3525Nm

Manufacturer: INGERSOLL RAND

SKU : W9491-K4E-EU

EAN13 : 0663023155807

3525Nm 20V cordless impact wrench with a 1" square drive

Has 3,000Nm of fastening torque and 3,525Nm of breakaway torque

Includes the cordless impact wrench, four 20 V, 5.0 Ah Li-Ion batteries and a dual charger

Has a three year warranty

£1,182.72 £985.60
In stock

Free UK Delivery on orders over £75 including VAT

Live Chat Icon

Need shopping help?

Ask a Specialist

Product Information

  • This 20 volt cordless impact wrench has a short anvil and combines the power of compressed air with the freedom of cordless mobility, enabling the operator to move freely.
  • It offers 3,000Nm of fastening torque and 3,525Nm of breakaway torque.
  • The IQV power control system includes four modes -
    • Full power in reverse
    • Lockout at 250Nm
    • Lockout at 550Nm
    • Full power forward
  • It has a switch for variable speed adjustment and an electronic brake for maximum control to enhance safety.
  • IP56-rated, which means this impact wrench is protected from dust and particles in the air as well as powerful jets of water.
  • Has an impact and chemical-resistant composite housing.
  • The set includes the cordless impact wrench, four 20 V, 5.0 Ah Li-Ion batteries and a dual charger.

Technical Details

Drive Size 1"
Grip Type D Handle
Blows Per Minute [BPM] 1,170
Number of Batteries Required 2
Drive Type Square
Anvil Length Standard
Built-In Light No
Hand Tight Free Speed [RPM] 500
Impact Mechanism Ball and Cam
Lubrication 67-1 LB
Motor Brushless Motor
Standards/Certifications Ul Listed, Csa Certified, IP56 rated
Wireless Tool Tracking No
Number of Batteries Included 4
Forward/Fastening Torque [ft-lb] 2200 ft-lb
Forward/Fastening Torque [Nm] 3000 Nm
Half Power Forward Torque [ft-lb] 400 ft-lb
Half Power Forward Torque [Nm] 550 Nm
Maximum Hand Tight Forward Torque [ft-lb] 180 ft-lb
Maximum Hand Tight Forward Torque [Nm] 250 Nm
Height 206 mm
Impacting Sound Power 105 dB
Impacting Sound Pressure 94 dB
Maximum Bolt Diameter 1.25 "
Maximum Free Speed 890 RPM
Maximum Reverse Torque [ft-lb] 2200 ft-lb
Maximum Reverse Torque [Nm] 3000 Nm
Power to Weight Ratio [Nut-busting Torque/Weight] 94.55 ft-lb
Total Length 511 mm
Vibration Level 25.8 m/s2
Voltage 20 V
Weight 11020 g
