Compression Cable Lugs
A compression cable lug is an electrical connector that is used to terminate a cable onto a fixed connection point, such as a panel, busbar, transformer or battery terminal.
Compression cable lugs are designed for applications where a secure mechanical and electrical connection is needed between a conductor and a fixed connection point.
They are commonly used by electricians, panel builders and cable assembly technicians because they provide a stable, reliable and low-resistance connection when correctly crimped onto a cable. Compression cable lugs are used to terminate cable in high-voltage machinery, as well as where high levels of vibration may be present, such as in road vehicles, trains and aircraft.
-

373R12
Klauke 373R12 (M12) 300mm² Compression Cable Lug - Copper/Aluminium£28.10 £23.42300mm² lug for non-tension aluminium and pre-rounded sector conductors
Tube dimension to DIN 46329
Highly visible code number for clear tool assignment
Filled with contact grease for optimum crimp results

-

L166MS
Klauke L166MS (M6) 16mm² Copper Cable Lug - Tin Plated£1.04 £0.87Tubular cable lug for stranded connectors, e.g. VDE 0295 class 2
For pre-rounded sector shaped conductors
Straight barrel with i-Flare internal chamfer for easy cable insertion
Made from copper according to EN 13600

-

L40012MS
Klauke L40012MS (M12) 400mm² Copper Cable Lug - Tin Plated£35.86 £29.88Tubular cable lug for stranded connectors, e.g. VDE 0295 class 2
For pre-rounded sector shaped conductors
Straight barrel with i-Flare internal chamfer for easy cable insertion
Made from copper according to EN 13600

-

L24012MS
Klauke L24012MS (M12) 240mm² Copper Cable Lug - Tin Plated£13.70 £11.42Tubular cable lug for stranded connectors, e.g. VDE 0295 class 2
For pre-rounded sector shaped conductors
Straight barrel with i-Flare internal chamfer for easy cable insertion
Made from copper according to EN 13600

-

L30012MS
Klauke L30012MS (M12) 300mm² Copper Cable Lug - Tin Plated£21.49 £17.91Tubular cable lug for stranded connectors, e.g. VDE 0295 class 2
For pre-rounded sector shaped conductors
Straight barrel with i-Flare internal chamfer for easy cable insertion
Made from copper according to EN 13600

-

L9510MS
Klauke L9510MS (M10) 95mm² Copper Cable Lug - Tin Plated£4.37 £3.64Tubular cable lug for stranded connectors, e.g. VDE 0295 class 2
For pre-rounded sector shaped conductors
Straight barrel with i-Flare internal chamfer for easy cable insertion
Made from copper according to EN 13600

-

L358MS
Klauke L358MS (M8) 35mm² Copper Cable Lug - Tin Plated£1.86 £1.55Tubular cable lug for stranded connectors, e.g. VDE 0295 class 2
For pre-rounded sector shaped conductors
Straight barrel with i-Flare internal chamfer for easy cable insertion
Made from copper according to EN 13600

-

L15010MS
Klauke L15010MS (M10) 150mm² Copper Cable Lug - Tin Plated£8.35 £6.96Tubular cable lug for stranded connectors, e.g. VDE 0295 class 2
For pre-rounded sector shaped conductors
Straight barrel with i-Flare internal chamfer for easy cable insertion
Made from copper according to EN 13600

-

L12010MS
Klauke L12010MS (M10) 120mm² Copper Cable Lug - Tin Plated£6.40 £5.33Tubular cable lug for stranded connectors, e.g. VDE 0295 class 2
For pre-rounded sector shaped conductors
Straight barrel with i-Flare internal chamfer for easy cable insertion
Made from copper according to EN 13600

-

L63016MS
Klauke L63016MS (M16) 630mm² Copper Cable Lug - Tin Plated£43.37 £36.14Tubular cable lug for stranded connectors, e.g. VDE 0295 class 2
For pre-rounded sector shaped conductors
Straight barrel with i-Flare internal chamfer for easy cable insertion
Made from copper according to EN 13600

-

L18512MS
Klauke L18512MS (M12) 185mm² Copper Cable Lug - Tin Plated£11.20 £9.33Tubular cable lug for stranded connectors, e.g. VDE 0295 class 2
For pre-rounded sector shaped conductors
Straight barrel with i-Flare internal chamfer for easy cable insertion
Made from copper according to EN 13600

-

L7010MS
Klauke L7010MS (M10) 70mm² Copper Cable Lug - Tin Plated£3.24 £2.70Tubular cable lug for stranded connectors, e.g. VDE 0295 class 2
For pre-rounded sector shaped conductors
Straight barrel with i-Flare internal chamfer for easy cable insertion
Made from copper according to EN 13600

-

L508MS
Klauke L508MS (M8) 50mm² Copper Cable Lug - Tin Plated£2.36 £1.97Tubular cable lug for stranded connectors, e.g. VDE 0295 class 2
For pre-rounded sector shaped conductors
Straight barrel with i-Flare internal chamfer for easy cable insertion
Made from copper according to EN 13600

-

L106MS
Klauke L106MS (M6) 10mm² Copper Cable Lug - Tin Plated£0.73 £0.61Tubular cable lug for stranded connectors, e.g. VDE 0295 class 2
For pre-rounded sector shaped conductors
Straight barrel with i-Flare internal chamfer for easy cable insertion
Made from copper according to EN 13600

-

L50016MS
Klauke L50016MS (M16) 500mm² Copper Cable Lug - Tin Plated£37.64 £31.37Tubular cable lug for stranded connectors, e.g. VDE 0295 class 2
For pre-rounded sector shaped conductors
Straight barrel with i-Flare internal chamfer for easy cable insertion
Made from copper according to EN 13600

-

L66MS
Klauke L66MS (M6) 6mm² Copper Cable Lug - Tin Plated£0.71 £0.59Tubular cable lug for stranded connectors, e.g. VDE 0295 class 2
For pre-rounded sector shaped conductors
Straight barrel with i-Flare internal chamfer for easy cable insertion
Made from copper according to EN 13600

-
270R12V
Klauke 270R12V (M12) 185mm² Aluminium Compression Cable Lug£7.58 £6.32185mm² non-tension aluminium compression lug to DIN 60228 / EN 50182
For use on pre-rounded sector shaped conductors
Adheres to DIN 46329. item designation is on the cable lug
Made from E-aluminium, which has a tin plated surface (20 μm)

-
268R12V
Klauke 268R12V (M12) 120mm² Aluminium Compression Cable Lug£6.25 £5.21120mm² non-tension aluminium compression lug to DIN 60228 / EN 50182
For use on pre-rounded sector shaped conductors
Adheres to DIN 46329. item designation is on the cable lug
Made from E-aluminium, which has a tin plated surface (20 μm)

-
269R12V
Klauke 269R12V (M12) 150mm² Aluminium Compression Cable Lug£6.30 £5.25150mm² non-tension aluminium compression lug to DIN 60228 / EN 50182
For use on pre-rounded sector shaped conductors
Adheres to DIN 46329. item designation is on the cable lug
Made from E-aluminium, which has a tin plated surface (20 μm)

-
267R12V
Klauke 267R12V (M12) 95mm² Aluminium Compression Cable Lug£4.85 £4.0495mm² non-tension aluminium compression lug to DIN 60228 / EN 50182
For use on pre-rounded sector shaped conductors
Adheres to DIN 46329. item designation is on the cable lug
Made from E-aluminium, which has a tin plated surface (20 μm)

-
271R12V
Klauke 271R12V (M12) 240mm² Aluminium Compression Cable Lug£8.87 £7.39240mm² non-tension aluminium compression lug to DIN 60228 / EN 50182
For use on pre-rounded sector shaped conductors
Adheres to DIN 46329. item designation is on the cable lug
Made from E-aluminium, which has a tin plated surface (20 μm)

-

170R1245
Klauke 170R1245 (M12) 150mm² 45° Angled Compression Cable Lug - Copper & Tin Plated£16.01 £13.3445° compression lug with flat contacts and internal chamfer for safe connection
Reliable assignment due to item designation on the cable lug
Made from copper (EN13600) and is tin-plated to protect against corrosion
For round conductors, e.g. to DIN EN 60228 Cl. 1, 2, 5 and 6

-

163R645
Klauke 163R645 (M6) 16mm² 45° Angled Compression Cable Lug - Copper & Tin Plated£3.08 £2.5745° compression lug with flat contacts and internal chamfer for safe connection
Reliable assignment due to item designation on the cable lug
Made from copper (EN13600) and is tin-plated to protect against corrosion
For round conductors, e.g. to DIN EN 60228 Cl. 1, 2, 5 and 6

-

169R1045
Klauke 169R1045 (M10) 120mm² 45° Angled Compression Cable Lug - Copper & Tin Plated£12.37 £10.3145° compression lug with flat contacts and internal chamfer for safe connection
Reliable assignment due to item designation on the cable lug
Made from copper (EN13600) and is tin-plated to protect against corrosion
For round conductors, e.g. to DIN EN 60228 Cl. 1, 2, 5 and 6
