KLAUKE EK SD 50ML Electromechanical Wire Stripping and Cutting Tool 6mm² - 35mm²

KLAUKE EK SD 50ML Electromechanical Wire Stripping and Cutting Tool 6mm² - 35mm²

Manufacturer: KLAUKE

SKU : EKSD50ML

EAN13 : 4059580000000

Compact and mobile wire stripper thanks to the innovative PowerSense technology

One tool for all common insulation types

Strips wire from 6mm² - 35mm²

Replacing inserts is fast and easy

Can cut up to a diameter of 11.5mm

Click here for product info
£888.00 £740.00
In stock
  • Available to back order for dispatch on 07/11/2024

Free UK Delivery on orders over £75 including VAT

Live Chat Icon

Need shopping help?

Ask a Specialist

Product Information

  • One tool for stripping all common insulation types.
  • The cutting and stripping inserts are fast and easy to replace and one insert performs both actions.
  • Requires minimal effort for cutting and stripping, making this the perfect tool to use for long periods of time.
  • One-button operating concept for controlling all tool functions.
  • Automatic retraction when operation is complete although manual retract can be used when required.
  • Stripping length adjustable via cable stop, up to 28mm.
  • Designed for right-or-left hand use.
  • Powerful 10.8V Li-Ion battery with charge status display.
  • LED light on the tool to light up the job at hand.
  • Maintenance display shown via LED.
  • Project-based reporting with Klauke Link® app software package.
  • For use on all common insulation types (PVC, halogen-free, rubber, silicone, XLPE) up to a maximum outer diameter of 11.5mm.
  • Conductor classes : 1 - Single-stranded round conductor 2 - Multi-stranded round conductor 5 - Fine-stranded round conductor 6 - Ultra fine-stranded round conductor.

Technical Details

Manufacturer Klauke
Insulated [VDE] No
Can Cut Through Copper
Head Type Open
Hydraulic or Battery Powered Battery
Grip Type In-line
Battery Capacity 2.5 Ah
Battery Voltage 10.8 V
Can Strip From [mm] 6 mm
Can Strip To [mm] 35 mm
Charging Time 45 Minutes
Maximum Cutting Capacity 11.5 mm
Total Length 357 mm
Weight 1.8 kg
Weight Including Battery 0.96 kg
Wire Stripping Length 28 mm

Customer Questions & Answers

Customer Questions
No Questions
Did you find what you were looking for?

Product Attachments

Set Includes

Product Voltage Weight
LGML1 230 V 0.5 kg
Part No. Description
SD5010 Stripping insert 10mm²
SD5016 Stripping insert 16mm²
SD5025 Stripping insert 25mm²
SD5035 Stripping insert 35mm²
SD50CS Cable stop
RAML1225 Akku 10.8 V / 2.5 Ah, Li-Ion (27 Wh) battery
