KNIPEX 12 72 190 NexStrip® Multi-Tool for Wire Cutting, Stripping and Crimping

New

KNIPEX 12 72 190 NexStrip® Multi-Tool for Wire Cutting, Stripping and Crimping

Manufacturer: KNIPEX

SKU: 12 72 190

EAN13: 4003773088165

Back order for delivery on 11th May 2026

Multi purpose tool for wire stripping, cutting and crimping

Quick, precise square crimp of single wire ferrules

Stripping with fine adjustment

Clean cut of copper and aluminum conductors fine-stranded up to 10 mm²

High-quality housing made of glass fibre reinforced plastic

Click here for product info
£121.79 £101.49
In stock
GBP

Free UK Delivery on orders over £75 including VAT

Live Chat Icon

Need shopping help?

Ask a Specialist

Product Information

  • The KNIPEX 12 72 190 NexStrip combines cutting, stripping and crimping functions in one compact tool for efficient electrical work.
  • Automatically adjusts to cable diameter for precise, damage-free stripping from 0.03 to 10 mm².
  • Ensures consistent stripping lengths with an adjustable length stop, ideal for repetitive tasks.
  • Delivers fast, reliable square crimping of wire ferrules from 0.25 to 4 mm² in accordance with DIN 46228.
  • Features a ratcheting crimp mechanism to guarantee correct pressure and consistently high-quality results.
  • Cuts copper and aluminium conductors cleanly, handling fine-stranded wires up to 10 mm² and solid wires up to 6 mm².
  • Self-adjusting crimping die allows quick switching between different ferrule sizes without manual adjustment.
  • Includes fine adjustment settings for optimal performance with various insulation materials and temperatures.
  • Multi-component grips provide a comfortable, secure hold for improved control during prolonged use.
  • Constructed with a durable glass fibre reinforced plastic housing for long-lasting performance.

Technical Details

Manufacturer KNIPEX
Maximum Crimp Range of Twin Cable End-Sleeves 2 x 2.5mm²
Can Strip From [mm] 0.03 mm
Can Strip To [mm] 10 mm
Crimping Range From 0.25 mm²
Crimping Range Up To 4 mm²
Cutting Performance Medium-Hard Wire Diameter 6 mm
Cutting Performance Soft Wire Diameter 10 mm
Height 110 mm
Total Length 190 mm
Weight 170 g
Width 17 mm
Can Strip From [AWG] 32
Can Strip To [AWG] 8
Can Strip Cable Diameter 10mm
Packaged Weight 190 g
