Ingersoll Rand IQI Series Transducerised Torque Electric Screwdrivers 0.02 - 15 Nm

New

Ingersoll Rand IQI Series Transducerised Torque Electric Screwdrivers 0.02 - 15 Nm

Manufacturer: INGERSOLL RAND

SKU: IQI

±3.5% accuracy to minimize assembly errors and significantly lower rework costs

Provides real-time torque feedback and advanced error-proofing, ensuring every fastener is secured correctly

Real-time traceability and live access to production data enhances continuous quality control

Stores up to 32 parameter sets and 64 jobs per tool

Built to last over 1 million cycles

ESD-safe construction

Click here for product info
Out of stock

Free UK Delivery on orders over £75 including VAT

Live Chat Icon

Need shopping help?

Ask a Specialist

Product Information

  • Ingersoll Rand IQI Series Transducerised low-torque electric screwdrivers are the perfect tool for minimising assembly errors and maximising efficiency.
  • For use with the IQi11-FM, IQi Series Electric Screwdriver Controller.
  • Capable of ±3.5% accuracy and can provide real time torque feedback, advanced error-proofing and full process traceability, ensuring every fastener is secured correctly.
  • Also featuring seamless MES / Fieldbus & automation integration and live traceability and access to production data for continuous quality monitoring.
  • With industry first configurable tilt angle control to prevent cross-threading and maintain joint integrity.
  • Setup systems up to 50% faster with the Ingersoll Rand web based interface with full remote programming, diagnostics and control to minimize on-site intervention.
  • Stores up to 32 parameter sets and 64 jobs per tool.
  • Built to last over 1 million maintenance-free cycles.
  • Durable brushless motor and robust build extends lifespan and reduces tool replacement.
  • Ergonomic rubber grip increases operator comfort.
  • Push-to-start or trigger start activation modes.
  • 360° multi-colour LED status beam ring for instant cycle feedback and task lighting.
  • ESD-safe construction for electronics assembly and sensitive applications.

ALL PRODUCTS IN THIS RANGE

Model Number Power Supply Actuation Type Torque (Nm) Torque (in-lbs) Speed (rpm) Weight (g) Weight (lbs) Drive Type Length (mm) Length (in) Side to Centre Distance (mm) Side to Centre Distance (in)
IQI2LT0017TQ4IQI-PS-1Lever Start0.02-0.170.17-1.550-15004601.011/4" QC2439.5725.51.0
IQI2LT0017TM4IQI-PS-1Lever Start0.02-0.170.17-1.550-15004601.01Half Moon2439.5725.51.0
IQI2LT0050TQ4IQI-PS-1Lever Start0.1-0.50.88-4.420-10004601.011/4" QC2439.5725.51.0
IQI2LT0100TQ4IQI-PS-1Lever Start0.2-11.8-8.820-10004601.011/4" QC2439.5725.51.0
IQI2LT0200TQ4IQI-PS-1Lever Start0.4-23.5-17.720-8004601.011/4" QC2439.5725.51.0
IQI2LT0250TQ4IQI-PS-1Lever Start0.5-2.54.4-22.120-5254601.011/4" QC2439.5725.51.0
IQI4LT0500TQ4IQI-PS-2Lever Start2-517.7-4420-9008501.871/4" QC2489.7630.51.2
IQI4LT1000TQ4IQI-PS-2Lever Start4-1035-8810-5008501.871/4" QC2489.7630.51.2
IQI4LT1500TQ4IQI-PS-2Lever Start5-1544-13310-3008501.871/4" QC2489.7630.51.2

Technical Details

Manufacturer Ingersoll Rand
Drive Size 1/4"
ESD Safe Yes
Grip Type In-line
Drive Type Quick Change
Accuracy +/- 3.5%
Actuation/Throttle Type/Switch Type Push/Lever Start
Built-In Light Yes
Maximum Adjustable RPM 1500
Minimum Adjustable RPM 10
Grip Diameter 34 mm
Maximum Torque 15 Nm
Minimum Torque 0.02 Nm
Side to Center Distance 30.5 mm
Total Length 272 mm
Weight 880 g
Data Recording Yes
Tool Finder Yes
